This is our CAD-KAS PDF Editor with another user interface released under the name CreativDoc PDF Editor. Buy the user interface you like more. CAD-KAS PDF Editor









CreativDoc PDF Editor



1. PDF Editor - Introduction

CreativDoc PDF Editor is an application to edit and work with existing pdf files. After opening a pdf file you can use the pointer tool to select existing objects. You can select multiple objects at once to modify all at once. Over the property editor at the bottom of the window you can change selected objects. For example you may change the font or edit the text of a text object. You can call the picture editor to edit pictures or scanned files. At the right side of the window you find a color palette to change the text color and the color of line objects. If no object is selected you can call the page manager from the property editor panel to combine pdf files. add, delete, move, rotate, resize or extract pages. You also find a function to add page numbers or headers and footers there. The bookmark manager allows you to add new bookmarks or delete existing once. In the toolbar at the left side of the program you find tools to add new text and picture objects. Tools to add circles, rectangles, lines or freehand lines are found in the graphic object section. But you may also choose to add these objects as annotation objects which lay at the top of the regular document objects and can have an annotation message as property. In the annotation section you will also find the functions needed to markup text (highlight, strikeout, underline). In the form tool section you find all tools needed to add new form fields (text fields, checkboxes, radioboxes, list fields and comboboxes). You can select existing annoation and form fields objects with the pointer tool to modfiy there properties (for example fill out a form field). Finally you find a tool to add links to the document and a function to define pictures as stamps so you always need only one mouse click to add a picture you need often. You can use a grid to align selected objects when you need to move them. You may also display a ruler. If objects are selected you can move them arround, but if you click once on the selection you also have the option to rotate the selected objects with the mouse. You can encrypt or decrypt pdf files with the security settings under File/Properties. There you can secify a password an a set of limitations for the pdf file. You can export the pdf file as word or text file. In the edit menu you also find a function to search and replace text.

Download PDF Editor trial

Get it from CNET Download.com!

Purchase PDF Editor

3d2f.com editors have called the program "the best among the like"

Award from Discoveres.com Awards From Download2PC to PDF Editor - One of the best software download website. 5 stars award from www.download25.com DownloadRage - Games and Free Software Downloads PDF Editor awards 4 stars on FreeSafeSoft.com Award from
Discoveres.com FREE Downloads, Discount Software, Freeware, Games, Submissions & More

2. Key features

  • Open/Save existing pdf files
  • Move/Delete/Rotate/Resize/Copy/Paste of all objects
  • Change text, font, color
  • Picture editor
  • Combine pdf files
  • Move/Delete/Split/Extract/Rotate/Resize pages
  • Add text/pictures/lines/circles/rectangles
  • Add form fields
  • Fill out/Move/Resize/Rotate form fields
  • Add annotations
  • Markup text
  • Add links
  • Manage bookmarks
  • Encrypt/Decrypt
  • Stamp function
  • Page number/header/footer function
  • Export as Word or Text file
  • Search and replace of text
  • Align to grid
  • Ruler
  • Align selected objects to the left/top/right/bottom side

3. How to change PDF files

3.1 Edit PDF objects

You can use the pointer tool to select existing objects. You can select multiple objects at once to modify all at once (hold the CTRL key down). Over the property editor at the bottom of the window you can change selected objects. For example you may change the font or edit the text of a text object. You can call the picture editor to edit pictures or scanned files. At the right side of the window you find a color palette to change the text color and the color of line objects. If objects are selected you can move them arround, but if you click once on the selection you also have the option to rotate the selected objects with the mouse.

In the edit menu you find functions to copy, paste and delete objects. If you want to copy from one pdf file to another you would need to combine both pdf files and make your copy and paste operations, finally you can delete all pages you do not need. Call the Page manager under Page/Page Manager to combine pdf files.

You can use a grid to align selected objects when you need to move them (in the View menu). You may also display a ruler.

3.2 Add objects to a PDF file

In the toolbar at the left side of the program you find tools to add new text and picture objects. Tools to add circles, rectangles, lines or freehand lines are found in the graphic object section. But this you may also choose to add these objects as annotation objects which lay at the top of the regular document objects and can have an annotation message as property. In the annotation section you will also find the functions needed to markup text (highlight, strikeout, underline). In the form tool section you find all tools needed to add new form fields (text fields, checkboxes, radioboxes, list fields and comboboxes). You can select existing annoation and form fields objects with the pointer tool to modfiy there properties (for example fill out a form field). Finally you find a tool to add links to the document and a function to define pictures as stamps so you always need only one mouse click to add a picture you need often.

3.3 PDF Page manager

You can call the Page Manager with a click on Page/Page Manager. There you can combine, add, delete, move, rotate, resize or extract pages. You also find a function to add page numbers or headers and footers there

3.4 PDF Security

You can encrypt or decrypt pdf files with the security settings under File/Properties.  There you can secify a password an a set of limitations for the pdf file

3.5 PDF Bookmarks

If no object is selected (Edit/Select nothing) you can call the bookmark manager over the property editor at the bottom of the main window. You can add new bookmarks you delete existing bookmarks there.

3.6 PDF Form fields

You can select existing form fields objects with the pointer tool to modfiy there properties (for example fill out a form field). In the form tool section of the toolbar at the left side of the main window you find all tools needed to add new form fields (text fields, checkboxes, radioboxes, list fields and comboboxes).

3.7 PDF Links

You find the function to add new links in the toolbar at the left side of the main window. Click into the document to create a new link. You can select exisitng link fields with the pointer tool.

3.8 PDF Stamps

In the toolbar at the left side of the main window you find the stamp function. First click on add new stamp and load you picture from hard disk. The new stamp will be displayed as new icon in the toolbar and can be selected as tool. If you click into the document the stamp will be added.

3.9 PDF text markup

You find the text markup functions in the section of the annotation tools in the toolbar at the left side of the main window. For text objects you can use the highlight, strikeout and underline function. For scanned files you can use the free highlight function to markup the text shown in the picture.

3.10 Convert PDF files to word files or text files

You can export the content of the pdf file as word file with text objects or without text objects (floating text). Floating text will mean it will be easy to use the text and copy and paste it as whole. If you have text objects the layout will be better maintained but you can only work within one object at once.

3.11 Print PDF files

The program has an integrated print function but you can also call the default pdf viewer application to print the file. This will in most cases produce results in better quality and will do the job faster.

3.12 Search and replace within PDF files

You can search and replace or only search within the PDF file through the functions in the edit menu. This functions are limited to use text objects at once and will not work if the searched text is divided into mulitple objects. The function may also fail if the font of the text uses a special encoding or the text is part of a picture object and not a text object (Scanned file)

3.13 Scanned PDF files

Scanned PDF files do not contain text objects so you need to select the picture and call the picture editor over the property panel at the bottom of the main window. There you can select the clone brush object to remove existing text. You hold the sift key down and click into a part of the picture where only background is shown. Now you can release the shift key and move over the text. The background will be copied over the text, this will remove the text.
